Functional useThrough the intelligent measuring device, the three-dimensional image of the vehicle profile and the comprehensive monitoring data of length, width, height, container rail height, wheelbase and pin wheelbase are obtained. For the semi-trailer type, the tractor and the trailer can pass through the system together, and the relevant information of the tractor and the trailer can be measured
Functional use
Through the intelligent measuring device, the three-dimensional image of the vehicle profile and the comprehensive monitoring data of length, width, height, container rail height, wheelbase and pin wheelbase are obtained. For the semi-trailer type, the tractor and the trailer can pass through the system together, and the relevant information of the tractor and the trailer can be measured at the same time, and the measurement can be completed at one time. And compare the monitoring data with the original data of the vehicle (or automatically compare and judge the original data of the vehicle outline size in the database of the vehicle management office), which is convenient for the vehicle management department or the vehicle inspection agency to supervise and manage the vehicle.
technical parameter
| product model | WGWK-100 | ||
| measuring range | Vehicle captain（m） | ≤22m | |
| Vehicle width（m） | ≤3m | ||
| Vehicle height（m） | ≤4.3m | ||
| wheelbase (of a vehicle)（m） | ≤12m | ||
| number of axles（个） | Within 6 axes (including 6 axes) | ||
| Measurement method | Driving in a straight line at low speed (about 5-10km/h) (passing type) | ||
| measurement error | ≤1% | ||
| Minimum indication | Length and height | 1mm | |
| wide | 1mm | ||
| Power supply | AC 220V ±10%，50Hz ±1Hz | ||
| operating ambient temperature | -10℃—50℃ | ||
| Ground leveling coefficient | <0.1% | ||
| relative humidity | ≤95% | ||
